    ZEMIC BM8D Shear Beam Stainless Steel Waterproof Load Cells 1000kg Weighing Platform Scale Load Cell Weighing Sensor

    Ask Lasest Price
    Brand Name : ZEMIC
    Model Number : B8D
    Certification : OIML
    Price : Negotiation
    Supply Ability : 500pcs/m
    Delivery Time : 15~25days
    • Product Details
    • Company Profile

    ZEMIC BM8D Shear Beam Stainless Steel Waterproof Load Cells 1000kg Weighing Platform Scale Load Cell Weighing Sensor

    ZEMIC BM8D Shear Beam Stainless steel waterproof Load Cells 1000kg Weighing Platform Scale Load Cell weighing sensor

    Specifications:


    Capacityt0.1/0.15/0.2/0.25/0.3/0.4/0.5/0.75/1/1.5/2/3/5/7.5/10
    lb250/500/750/1K/1.5K/2K/2.5K/2.5KLE/3K/4K/5K/5KSE/7.5K/10K/15K/20K
    AccuracyC2C3A5MB10M
    ApprovalOIML R60 C3
    Maximum number of
    verification intervals
    n max20003000500010000
    Minimum load cell
    verification interval
    VminEmax/5000Emax/10000Emax/15000Emax/10000
    Combined error(%FS)≤± 0.030≤± 0.020≤± 0.026≤± 0.050
    Creep(%FS/30min)≤± 0.024≤± 0.016≤± 0.017≤± 0.040
    Temperature effect
    on sensitivity
    (%FS/10℃)≤± 0.017≤± 0.011≤± 0.013≤± 0.040
    Temperature effect
    on zero
    (%FS/10℃)≤± 0.023≤± 0.015≤± 0.014≤± 0.020
    Output sensitivity(mv/v)3.0±0.008
    Input resistance()350±3.5
    Output resistance()350±3.5
    Insulation resistance()≥ 5000(50VDC)
    Zero balance(%FS)1.0
    Temperature,
    compensated
    (℃)-10~+40
    Temperature,allowed(℃)-35~+65
    Excitation,
    Recommended
    (V)5~12(DC)
    Excitation,Max(V)18(DC)
    Safe overload(%FS)150
    Ultimate overload(%FS)300

    Description:


    Zemic Load Cell B8D 0.5t to 10t OIML Approval

    1. B8D load cells are available in the capacities 250lb to 20Klb and 0.5t to 5t.

    2. Stainless steel construction, potted by adhesive inside.oil-proof,waterproof and anti-corrosive gas and medium making it suitable for all kinds of environments.

    3. Single shear beam, easy for installation, suitable for electronic truck scales, automobile testing facilities, hopper scales and other electronic weighing devices.

    4. Safe and anti-explosive product, can be used in atrocious environment and hazardous areas.

    Important Features
    1. Capacities: 250lb to 20Klb and 0.5t to 5t.
    2. High accuracy.
    3. Stainless steel construction.
    4. Low profile.
    5. With OIML approval.


    Applications:

    It is widely used in platform scale, truck scale and other electronice weighing devices.


    Competitive Advantage:
    1. High Quality:
    We have strict quality control system, all of our products comply with international quality standards and are greatly in a variety of different markets throughout the world.

    2. Outstanding Customer Service
    We are a professional manufacturer and exporter committed to weighing equipments research and manufacture. We have good English speakers , will give every clients timely response.

    3. Low MOQ & Fast Delivery:
    Small order quantity and flexible payment terms, it can meet your promotional business very well.
    Fast delivery, it can meet your urgent needs.
